Product Overview
Engine Rated Power kW/HP:
162
Engine Rated Speed r/min:
2200
Dimensions (L×W×H) mm:
5489×2997×3330
Max. Ballast Mass Front/Rear kg:
1000/400
Front Track (Factory Track) mm:
1923-2127（1923）
Rear Track (Factory Track) mm:
1846-2256 (1923-2518 with dual rear wheels)
Tire Model (Front/Rear):
16.9R30/20.8 R42 (radial) (dual rear tires)
Min. Turning Radius (without Braking) m:
≤6.5
Min. Ground Clearance mm:
392
Number of Gears:
30F+25R
Speed Range km/h Forward:
1.9～36.4
Speed Range km/h Reverse:
2.2～29.2
Rated Drawbar Pull kN:
49
PTO Power kW:
138
Depth Control Mode:
Position control, float control
PTO Speed (r/min):
540/1000
