Product Overview
Engine Rated Power kW/HP:
110.3
Engine Rated Speed r/min:
2200
Dimensions (L×W×H) mm:
5160×2610×3085
Max. Ballast Mass Front/Rear kg:
720/300
Front Track (Factory Track) mm:
1908-2208
Rear Track (Factory Track) mm:
1819-2340
Tire Model (Front/Rear):
14.9-28/18.4-38 (dual tires available)
Min. Turning Radius (without Braking) m:
≤7.1
Min. Ground Clearance mm:
417
Number of Gears:
16F+12R
Speed Range km/h Forward:
2.8～37.1
Speed Range km/h Reverse:
3.2～22.1
Rated Drawbar Pull kN:
34
PTO Power kW:
95
Depth Control Mode:
Force control, position control, force-position combined control and float control
PTO Speed (r/min):
540/1000
