Dongfanghong-LD1804

YTO Group (YTO)

Write a Review
SKU:
Dongfanghong-LD1804-4WD

Product Overview

Application:
Designed for subsoiling, plowing, combined land preparation, combined operations and transport, for various field work. It is a 180-HP-class, TG reinforced chassis, high-clearance 4WD tractor.

Highlights:
The Dongfanghong LD1804 series is a TG-reinforced-chassis 4WD tractor developed by YTO for various field combined operations. It is equipped with either a SDEC SC7H series four-valve high-pressure common-rail or a Dongfanghong 6M series six-cylinder turbo-intercooled engine, with ample power, economy and environmental performance; a 16F/8R combination transmission with optional synchromesh shifting and 36+12 creeper gears; a dry single-plate main clutch with air-assist; a wet electro-hydraulic PTO clutch with cushioning, push-button operated for maintenance-free use; high lift with main cylinder + dual auxiliary cylinders and 3-spool slide-valve hydraulic outlets; a 280 L large fuel tank to reduce refueling frequency; a fully enclosed air-conditioned cab with a 7-inch LCD color display, rear-view camera and LED work lights for comfort; rear sliding axle for stepless tread adjustment, optional front-single/rear-dual or radial tires for better flotation.

Engine Rated Power kW/HP:
132.5

Engine Rated Speed r/min:
2200

Overall Dimensions (L×W×H) mm:
5430×2770×3310

Maximum Ballast Weight Front/Rear kg:
540/300

Front Track Width (Factory) mm:
1770-2208

Rear Track Width (Factory) mm:
1730–2342 (2342 with dual rear wheels)

Tire Model (Front/Rear):
16.9-28/20.8-38

Minimum Turning Radius (Without Braking) m:
≤7.3

Minimum Ground Clearance mm:
490 (at front axle)

Number of Gears:
16F/8R

Forward Speed Range km/h:
3.02~38.95

Reverse Speed Range km/h:
5.21~13.52

Rated Drawbar Pull kN:
58.5

PTO Power kW:
118.5

Plowing Depth Control Method:
Position Control, Float Control

PTO Speed (r/min):
540/1000
