Dongfanghong-1604

YTO Group (YTO)

Write a Review
SKU:
Dongfanghong-1604-4WD

Product Overview

Application:
Designed for subsoiling, plowing, rotary tillage, combined land preparation and transport, for large-scale dry-land farming. It is a 160-HP-class, high-power, high-traction 4WD tractor.

Highlights:
The Dongfanghong 1604 series is a high-horsepower 4WD tractor developed by YTO on the same platform as the 1804/LX2204. It is equipped with a SDEC SC8DK190G3 six-cylinder turbocharged engine for high traction; a 12F+4R transmission; the main clutch has air-assist for low pedal effort, the auxiliary clutch and differential lock are electro-hydraulically controlled; position + float control with optional forced-down linkage; 3 hydraulic outlets with imported quick couplers; a 400 L large fuel tank for longer operation per fill; a new fully enclosed cab with wide visibility, heating/ventilation, air conditioning and an MP3 player for comfort; stepless adjustable rear tread, full hydraulic steering on an independent circuit, and optional dual rear wheels.

Engine Rated Power kW/HP:
118

Engine Rated Speed r/min:
2200

Overall Dimensions (L×W×H) mm:
5390×2850 (3470 with dual rear wheels) ×3450

Maximum Ballast Weight Front/Rear kg:
720/360

Front Track Width (Factory) mm:
1860-2176

Rear Track Width (Factory) mm:
1750-2060

Tire Model (Front/Rear):
14.9-28/18.4-38

Minimum Ground Clearance mm:
429

Forward Speed Range km/h:
2.25~29.06

Reverse Speed Range km/h:
4.25~11.47

Rated Drawbar Pull kN:
55.5

PTO Power kW:
105.8

PTO Speed (r/min):
540/1000
